785nm 500mW 0.2nm Narrow Line-width Raman Fiber Laser Source

785nm 500mW 0.2nm Narrow Line-width Raman Fiber Laser Source

785nm wavelength with 500mW output power fiber-coupled narrow linewidth laser for Raman spectroscopy. It has a central wavelength of 785nm and operates in continuous wave (CW) mode. The fiber core diameter is 100um with 0.22 NA. The optical fiber interface can be customized.

Note:
This is a custom product, if you need other output power, or have special requirements, please contact us.

[Lead Time]
785nm 500mW Raman Laser: 3~4 weeks

[Features]
1. Spectral linewidth: <0.2nm
2. Spectral stability: <0.005nm/℃

[Applications]
2. Raman spectroscopy
2. Sensing

[Specification]
Product Name: Narrow linewidth raman laser
Wavelength: 785nm
Output Power: 500mW (@ Fiber output side, and 0~max power adjustable)
Optical Fiber: 100um / NA 0.22 / SMA / 1 Meter
Operating Temperature: 0°C~45°C
Storage Temperature: -40°C~85°C
Modulation: 0~10KHz TTL
